MSI B450M PRO-M2 MAX AMD AM4 Gaming Motherboard Best Price in Bangladesh

MSI B450M PRO-M2 MAX AMD AM4 Gaming Motherboard

0 Customer Review

Model: MSI B450M PRO-M2 MAX
Product Code: 12608
Availability: Out Of Stock

Quick Overview

Key Features
Model: MSI B450M PRO-M2 MAX
Supports 1st, 2nd and 3rd Gen AMD Ryzen
AMD B450 Chipset
Turbo M.2 & Audio Boost Technology
X-Boost & Core Boost Technology

View More Info

Out Of Stock

+ -

Specification
Description
Reviews (0)

Specification:

Motherboard
Supported CPU	Supports 1st, 2nd and 3rd Gen AMD Ryzen/ Ryzen with Radeon Vega Graphics and 2nd Gen AMD Ryzen with Radeon Graphics/ Athlon with Radeon Vega Graphics Desktop Processors for Socket AM4
Chipset	AMD B450 Chipset
Form Factor	m-ATX
PCI	1 x PCIe 3.0 x16 slot (PCI_E1) - Supports x16 speed with AMD Ryzen 1st and 2nd Generation processors - Supports x8 speed with AMD Ryzen with Radeon Vega Graphics processors - Supports x4 speed with AMD Athlon with Radeon Vega Graphics Processors 2 x PCIe 2.0 x1 slots
M.2 Socket	1 x M.2 slot (Key M) - Supports PCIe 3.0 x4 (1st, 2nd and 3rd Gen AMD Ryzen/ Ryzen with Radeon Vega Graphics and 2nd Gen AMD Ryzen with Radeon Graphics) or PCIe 3.0 x2 (AMD Athlon with Radeon Vega Graphics)and SATA 6Gb/s 2242/ 2260 /2280 storage devices.
Type	DDR4
Slots	2
Supported Memory	Support DDR4 1866/ 2133/ 2400/ 2667Mhz(by JEDEC) - For AMD Ryzen Gen3 (R5/R7/R9) : - 2667/ 2800/ 2933/ 3000/ 3066/ 3200/ 3466/ 3733/ 3866/ 4000/ 4133 MHz (by A-XMP OC MODE) - For AMD Other CPU - 2667/ 2800/ 2933/ 3000/ 3066/ 3200/ 3466 MHz (by A-XMP OC MODE) Dual channel memory architecture Supports ECC UDIMM memory (non-ECC mode) Support non-ECC UDIMM memory
Maximum Memory	32GB
Graphics	1 x VGA port, supports a maximum resolution of 2048x1280@60Hz, 1920x1200@60Hz 1 x DVI-D port, supports a maximum resolution of 1920x1200@60Hz 1 x HDMI™ 1.4 port, supports a maximum resolution of 4096x2160@30H
Maximum Shared Memory	2048 MB
Display Port	Yes
USB	USB 3.2 PORTS (FRONT) : 2(Gen1, Type A) USB 3.2 PORTS (REAR) : 4(Gen1, Type A) USB 2.0 PORTS (FRONT) : 4 USB 2.0 PORTS (REAR) : 2
LAN Port	1x Realtek 8111H Gigabit LAN controller
Supported Storage	AMD B450 Chipset : - 4 x SATA 6Gb/s ports - Supports RAID 0, RAID1 and RAID 10 - 1 x M.2 slot (Key M) - Supports PCIe 3.0 x4 (1st, 2nd and 3rd Gen AMD Ryzen/ Ryzen with Radeon Vega Graphics and 2nd Gen AMD Ryzen with Radeon Graphics) or PCIe 3.0 x2 (AMD Athlon with Radeon Vega Graphics)and SATA 6Gb/s 2242/ 2260 /2280 storage devices
Audio	7.1-Channel High Definition Audio
Internal I/O Ports	1 x 24-pin ATX main power connector 1 x 8-pin ATX 12V power connector 4 x SATA 6Gb/s connectors 2 x USB 2.0 connectors (supports additional 4 USB 2.0 ports) 1 x USB 3.2 Gen1 connector (supports additional 2 USB 3.2 Gen1 ports) 1 x 4-pin CPU fan connector 1 x 4-pin system fan connector 1 x Front panel audio connector 2 x Front panel connectors 1 x Chassis Intrusion connector 1 x Serial port connector 1 x LED strip connector 1 x Clear CMOS jumper
Trusted Platform Module	1 x TPM module connector
Special Features	yes
Warranty	03 Years Warranty

Description :

MSI B450M PRO-M2 MAX AMD Gaming Motherboard

The MSI B450M PRO-M2 Max motherboard is a solid choice for building a system based on AMD Ryzen processors for AM4 socket. It is every factor rather than just one or two which are improved. Exclusive Core Boost technology allows for easy CPU overclocking while DDR4 Boost technology ensures stable memory performance. Enjoy ultra-fast storage speed by installing PCI-E SSD using the M.2 slot. Both data transfer and charging via USB will be accelerated for less wait time. The PCI-E steel slots are ready for long, heavy graphics card. The purest audio will be reproduced to let you aim your enemies precisely. Cooling your PC is essential for reliable performance. MSI motherboards feature excellent power design with solid and heavy heatsink. We've made sure to include enough fan headers with full control to allow you to cool your system any way you want. MSI motherboards featured all the latest solution for enthusiast gamers and prosumers. CPU and memory enhancement and fast storage and USB transfer speed are ready to be on the battlefield. MSI motherboards featured all the latest solution for enthusiast gamers and prosumers. CPU and memory enhancement and fast storage and USB transfer speed are ready to be on the battlefield. PRO Series motherboards combine stable functionality and high quality assembly for clever business solutions. Designed to satisfy any professional workflow, PRO Series motherboards make life easier for businesses and office use.
